1. Save paper
The world's first patent-protected, fully self-designed gripper-type double-sided paper feeding technology, to achieve double-sided multi-color printing at the same time, under the premise of enjoying the advantages of inkjet low-cost, McLantis digital printing machine can realize the printing of one sheet of paper and zero waste.
2. Strong ink applicability
There are many types of paper in the market, and the cost performance of ordinary double offset paper is better than that of coated paper. The current mainstream inkjet printing equipment is not very adaptable to ordinary double offset paper. We use our self-developed nano ink to be completely suitable for ordinary double offset paper, even at normal temperature without using a drying device, which greatly saves electricity costs.
3. Streaming data printing
For the fast printing market and the variable data market, the file formats that need to be processed are more complicated, and many have variable data such as barcodes. McLantis digital printing machine uses self-developed RIP, imposition and variable data output capabilities, which can achieve 1200 pages per minute. Calculate ability. Fully supports file queue streaming print output, when a job is finished output, the next job is automatically started.
4. Full color output without deviation registration
We have adopted the double-sided output technology of gripper, which makes the printing application wider. Realize zero double sheets, zero register error, can realize four-color accurate register, comparable to offset printing, stable printing of 9000 A3 sheets per hour, bringing you great convenience.
5. Color stability
We adopt automatic color calibration and dynamic ink compensation technology to make the printing color stable as always.
6. Insert label output
According to the number of pages of each job, it can automatically realize the output of inserting labels in sets.
| Model | DIGIMAC453CSF | DIGIMAC600CSF |
| Print Head | the latest high-speed cycle on-demand piezoelectric industrial-grade print head (high-speed, high-precision, cycle, variable dot printing) |
| Paper Feeding Method | Based on the roller-type sheet-fed equipment, the inkjet unit adopts a self-developed circulating ink supply system to achieve precise control of positive and negative pressure |
| Equipment Size | (length x width x height) 3mx2mx2.3m |
| Color Mode | black and white, two-color, full-color mode |
| Printing Mode | Ink saving mode (600*600), normal mode (600*800), deepening mode (600*1200) |
| Printing Method | 2, 4, 8 grade change point printing grayscale (300 dpi 4-level grayscale, equivalent to 1200DPI of the toner device) |
| Print Width | 453mm x 360mm | 600mm x 453mm |
| Printing Speed | 600ppm | 1200ppm |
| Paper Type | ordinary offset paper, newsprint, inkjet coated paper, carbonless copy paper |
| Paper Range | 40g-180g |
| Registration | 0.2mm |
| Power | 220V, 20KW (peak) | 220V, 30KW (peak) |
| Ink Type | The self-developed nano water-based pigment inks are used, and special inks can be customized for users |
| Drying Method | does not need to be dried (quick-drying ink) |
| Mechanical Transmission | Full servo control |
| Print Controller (hardware) | Four (two-color for four) blade servers (i7 processor, 32G memory, 1TB hard disk, 2 USB3.0 ports) |
| Print Controller (software) | 1. Obtain device status in real time and automatically control device printing; 2. Use self-developed RIP parser to support Doc, PDF, Tiff, Ps, AFP, JPG and other files; 3. Use the self-developed CMM system to achieve color correction for multi-color printing; 4. Support a variety of imposition methods such as flat stitching and saddle stitching, and the imposition method can be customized; 5. Support variable data typesetting and printing; 6. Support real-time printing of red badges and red heads and real-time data destruction (optional); 7. Support the self-developed order import and export of the network platform based on the JDF process (optional) |
|
|
