Digital printing UV Roll to Roll Inkjet Printing machine

Contact Now

Nowadays the UV Printing is the trend of advertisement printing. As it can print more kinds of material, and guarantee much more longer lifetime, and gives very impressive printing result. Especially for this new arrival DIGIMAC JETUV Series Machine, Epson DX8 And Epson i3200-U industrial heads are available, 2m and 3.2m as option, meet the requirement of different printing. With i3200-U Heads, speed can be up to 130sqm/h. And with 6 or 8 DX8 heads, it will achieve amazing embossing effect. Which can be maximum 5 layers printing. Advanced technology, makes it to be your professional business partner.

Model No.		DIGIMAC JET20UV	DIGIMAC JET20UVE	DIGIMAC JET32UV	DIGIMAC JET32UVE
Printhead		6 × Epson DX8 (8 Heads Available)		4 × Epson i3200-U
Resolution(dpi)		2880 dpi
	Width	2000 mm MAX		3200 mm MAX
Media	Type	Flex Banner, Vinyl, One Way Vision, Banner Cloth, Window Film, Mesh, Eco Solvent PP Paper, Eco Solvent Photo Paper…
	Color	CMYK LC LM + W + V		CMYK/CMYK + W
	Type	UV Ink
Ink	Curing	High quality water cooling UV-LED Lamp
	Test Color Mode	3×W +2×CMYK Lc Lm + 1×Varnish		CMYK
	Draft	6 sqm/h	8 sqm/h	108 sqm/h	130 sqm/h
	Standard	4.5 sqm/h	6 sqm/h	80 sqm/h	98 sqm/h
Speed	Quality	3.5 sqm/h	4.5 sqm/h	54 sqm/h	64 sqm/h
Ink Supply System		Two advanced separate negative pressure systems (One for color and varnish, One for white).
Cleaning System		Automatic Cleaning, Anti-Clogging Flash Function & Capping System
Feed & Take Up		Automatic Media Feeding (Standard) & Take Up System (Standard)
Environment		Temperature: 20-28°C, Humidity: 40-60%
Rip Software		Photoprint
Interface		USB3.0
Power		Machine 50/60Hz, 110/220V, 1500W
	Machine (mm)	3770 x 920 x 1710	5170 x 920 x 1710	3770 x 920 x 1710	5170 x 920 x 1710
Size	Packing (mm)	3870 x 1020 x 1940	5270 x 920 x 1940	3870 x 1020 x 1940	5270 x 920 x 1940
Weight	Machine	850KG	1000KG	850KG	1000KG
	Packing	1100KG	1300KG	1100KG	1300KG

Digital printing UV Roll to Roll Inkjet Printing machine Images
