Digital Textile Fabric DTF Printing machine

Contact Now

For the traditional screen printing, complicate pre-treating and after-treating are required. While with the belt fabric printer, which can work with disperse ink, pigment ink, acid ink and reactive ink, then print directly onto fabric easily. Especially for pigment ink, need only three steps: Printing, and heat fixation only. This digital printing make customize or DIY printing to be possible. And the belt type media feeding system, enable the printing of textile with different elasticity. Achieve maximum business potential.



Digital Textile Fabric DTF Printing machine

Digital Textile Fabric DTF Printing machine Digital Textile Fabric DTF Printing machine



Digital Textile Fabric DTF Printing machine Digital Textile Fabric DTF Printing machine





Model DIGIMAC JETTEX
Print Head Micro piezo printhead DX5 / i3200
Max Print Width 2200mm, 2600mm, 3200mm

Print Speed

(sqm /h)

 Print Head DX5 * 2pcs i3200 * 2pcs i3200 * 3pcs
Production mode 4 pass 30.6 4 pass 50.5 3 pass 97
Standard mode 6 pass 24 6 pass 31.6 4 pass 75
Quality mode 8 pass 15.4 8 pass 24.8 6 pass 50.5
Ink Type Dye Sublimation ink
Color Cyan, Magenta, Yellow, Black
Application T-shirts, cloths ,towers, home textile, pants, shoes, hats, scarves, curtains, umbrellas, cups, skateboards ...
Ink Supply Auto Ink supply system
Maintenance Of The Printhead One button cleaning printhead by solvent
Rip Software MainTop; PhotoPRINT
Data Interface USB 2.0 / USB 3.0
Assistant Option Feeding & Take up Auto Feeding And Take Up System
Heating System Stage heating system include back, front heating
Carriage Height 1 - 5 mm Distance to the printing platform , adjustable
Other Functions Light for carriage position
Printer Info Operating voltage AC 220V 50Hz/60Hz ( 110V Optional )
Power Print system:0.5kw ; Front 0.5kw ; Rear 0.5kw ; Back 1kw
Working Environment Temperature: 22 - 28 Humidity:40% - 70%
Printer Dimension 3200mm(L)x900mm(W) x1350mm(H) 200kg
Shipping Dimension 3360mm(L) x760mm(w) ×1020mm(H) 240kg
